400 series rubber hose


Raceworks 400 Series Rubber Hose has an inner liner of Nitrile which is reinforced with braid made from high tensile synthetic textile cord to give it extra strength. Raceworks 400 Series rubber hose is safe for use with E85, methanol, oils, lubricants and coolant. Recommended for use on low pressure systems/temperature applications. If using in high pressure or temperature above 70°C we recommend securing hose ends with a clamp. All Raceworks products come with a 2 year warranty.

Hose is not submersible.

Temperature Range: -40°C to 100°C. Ethanol & Methanol Safe.

For High temp applications, we recommend the use of our Fibre Glass heat sleaving


Size Operating Pressure Burst Pressure Inside dia Inch Inside dia mm Outside dia Inch Outside dia mm Weight (gm/m) Bend Radius (Inch) Bend Radius (mm)
AN-4   250psi   750psi   1/4″   6.4mm   29/64″   11.6mm   99g   1.18″   30mm
AN-5   250psi   750psi   5/16″   7.9mm   9/16″   14.2mm   140g   1.38″   35mm
AN-6   250psi   750psi   3/8″   9.5mm   5/8″   15.8mm   175g   1.58″   40mm
AN-8   250psi   750psi   1/2″   12.7mm   3/4″   19.1mm   237g   2.17″   55mm
AN-10   250psi   750psi   5/8″   15.8mm   15/16″   22.9mm   296g   2.44″   62mm
AN-12   250psi   750psi   3/4″   19.1mm   1-1/32″   26.2mm   353g   3.54″   90mm
SKU 400-series-hose
Brand Raceworks
